Three Operation Modes · Underslung Mode · Upright Mode · Briefcase Mode Built-in independent IMU module DJI Specialized Gimbal Drive Motors with Encoders Bluetooth Module USB Connection 2.4GHz Receiver Temperature Sensor DJI Advanced 32-Bit DSP Processor D-Bus Supported MECHANICAL & ELECTRICAL CHARACTERISTICS Working Current Static current: 300mA (@16V)

Dynamic current: 600mA (@16V)

Locked motor current: Max 10A (@16V) Operating Temperature   -15°C ~ 50°C (5°F ~ 120°F) Weight  4.20kg (9.26lbs) fully loaded with handlebar Gimbal Dimensions   620mm(W) x 280-380mm (D)x 500mm(H) Supported Camera Dimensions Maximum depth at center of mass on camera base plate: 140mm

Maximum height measured from top of camera base plate: 225mm

Maximum width: 195mm PERIPHERAL Accessory Power Connections 12V regulated P-Tap x 2, USB 500mW x 1, DJI Lightbridge x 1 GCU Input Power 4S Ronin Battery Connections 2.4GHz Remote Control, Bluetooth, USB PC Assistant Software Requirements  Windows XP SP3; Windows 7; Windows 8 (32 or 64 bit) Mobile Assistant Software Requirements  iOS version 6.1 or above Mobile Device iPhone 4s, iPhone 5, iPhone 5s, iPod touch 5 , iPad 3, iPad 4, iPad mini WORKING PERFORMANCE Load Weight (Reference Value)   7.25kg (16lbs) Angular Vibration Range ± 0.02° Maximum Controlled Rotation Speed   Pan axis: 90°/sec

Tilt axis: 100°/sec

Roll axis: 30° /sec Controlled Rotation Range   Pan axis control: 360° Tilt axis control: Up 45° to Down 120° Roll axis control: ± 25°
